Baden Tubular Dummy Helios Lever Right Door Entrance Set - Door Mount - 17" Brass/Satin Brass

Baden Tubular Dummy Helios Lever Right Door Entrance Set - Door Mount - 17" Brass/Satin Brass

SKU 4810HLORHUS4
by Emtek
Pre-order
$508.00
$508.00 - $508.00
$508.00
$406.00
$406.00 - $406.00
$406.00
See it live before you buy Click to call a specialist in our Miami Showroom right now

Delivery time

This product will ship from the manufacturer within 10 business days
[additional]

Included:

  • Interior trim deadbolt
  • Exterior trim beadbolt
  • Interior trim lever plate
  • Exterior trim handle plate
  • Installation hardware
  • Qty: 1

[/additional]

These dummy entry sets are constructed of solid forged brass, feature modern attractive design. Excellent way to secure your home with a sense of style.With a modern style, this dummy entry set is also available with key lock.Available in different finishes and functions.Also available the version with Motorized Smart Lock connected via Wi-Fi to your smartphone (only for single cylinder function)

Features

  • Handing required if Lever used on inside.
  • Available in Single Cylinder, Double Cylinder, or Dummy function.
  • Standard 2-1/8 in. bore door prep.
  • Standard door thickness of 1-3/4 in. Specify if thicker.
  • Standard backset 2 3/8". Specify 2 3/4" backset if required.
  • Exterior Handleset Overall Length: 16-3/8 in.
  • Exterior Upper Plate: 2-1/2 in. x 4 in. x 1/2 in. thick
  • Exterior Lower Plate: 1-3/4 in. x 2 in. x 1/2 in. thick
  • Exterior Grip: 1 in. thick
  • Clearance between Door & Grip: 1-7/8 in.
  • Exterior Projection: 2-1/2 in.
  • Exterior/Interior Deadbolt Trim: 2-1/2 in. x 2-1/2 in. x 5/8 in. thick
  • Interior Trim Plate: 2-1/2 in. x 2-1/2 in. x 1/2 in. thick
  • Dummy set for doors where only pull is required. No latch or strike.
  • Available in: Satin Brass, oil Rubbed Bronze, Polished Nickel, Satin Nickel, Matt Black, Polished Nickel and Unlacquered Brass
  • Material: Brass
  • Finish/Color: Satin Brass
  • Dimensions: W: 2,5" * H: 17,5" * D: 1,75"
  • Weight: 06 lb.
  • Rustproof: Yes
  • Warranty (Years): 1
  • Material Warranty: Yes
  • Finish Warranty: Yes
  • Easy Installation: Yes
